The JH-3500U SunVista Inverter

The Sharp JH-3500U is a 3.5 kW inverter designed to blend energy from up to three input strings,
each varying by number, model, and angle of modules. Having three distinct PV input strings
makes it possible to install systems on buildings with multiple roof planes, even if they face in
different directions. An active cooling system ensures that the inverter maintains stable power
output even in extreme temperatures.

Perfectly matched to Sharp modules and mounting hardware, the JH-3500U is also compatible
with many other manufacturers’ systems, and is ideal for both residential and commercial
applications. With over 60,000 units in the field, the Sharp SunVista has proven to be among
the most dependable and flexible inverters in the world. The SunVista is designed for easy field
serviceability and is backed by the strength of Sharps’ global electronic parts distribution network.

The JH-3500U is housed in a NEMA 3R enclosure and includes an indoor rated surface-mount
LCD display which displays instantaneous and cumulative electricity generation and CO reduction
levels. The inverter is IEEE 929 compliant and is listed to UL1741. It carries a five-year warranty.

Model	Efficiency	DC Input Voltage	Continuous Power Watts	AC Output Volts	Dimensions in.	Weight lb.	MSRP	Price
JH-3500U	91%	110-350	3500	240	23.7 x 17.8 x 7.85	61.7	$2999.99	$2,469.99
