Suitable for a Variety of Applications
The SunWize SW-S30P's are high quality 30-watt solar modules suitable for a variety of photovoltaic applications including remote communications, security, rural electrification, water pumping and general battery charging.
They can be used by themselves or in applications that require multiple modules.
When connected in series, you'll have sufficient voltage for battery charging under extreme high temperatures.
Junction Box
Their weather resistant junction box allows for all wiring methods including moisture-tight strain relief connectors and electrical conduit.
The bypass diodes insure reliable operation.
These polycrystalline modules consist of 36 solar cells.
SunWize Still Offers Smaller Solar Panels
While some of the larger manufacturers no longer manufacture solar panels in smaller wattages, SunWize has a good selection.
Be sure to check out all of our SunWize panels.
Warranty
The SunWize SW-S30P module is manufactured according to international and US quality standards and are guaranteed by 25-year limited warranty.
Electrical Performance under Standard Test Conditions (*STC)
Maximum Power (Pmax)
30w (+/-10%)
Maximum Power Voltage (Vmpp)
17.4V
Maximum Power Current (Impp)
1.72
Open Circuit Voltage (Voc)
22 V
Short Circuit Current (Isc)
1.88 A
Max System Voltage
50VDC
Current Temperature coefficient (Isc) -.0.065%C
Cells
Number per Module
36
Module Characteristics
Length x Width x Depth
21.38 x 20.04 x 1.97
Others
Voltage Temperature coefficient (Voc)
-0.35%/C
Current Temperature coefficient (Isc)
-.0.065%C
Power Temperature coefficient (Pmax) -0.5%/C
Peak Power Tolerance +/-10%
Fire Class Rating Class C
Please Note: These modules are not currently UL listed
